Product Out of Stock
Sorry, this product is temporarily out of stock.
Weathermatic Solenoid (S20PSA)
Weathermatic S20PSA
WeatherMatic #S20PSA
SOLENOID
Product Overview
Weathermatic S20PSA replacement solenoid
The Weathermatic S20PSA is a 24 VAC replacement solenoid for Weathermatic valves. Swap it into a valve that hums, chatters, or will not open, and skip replacing the whole valve body. It seats on the bonnet and drives the plunger that lets the diaphragm lift.
Specifications
| Voltage | 24 VAC, 60 Hz |
|---|---|
| Inrush | 9.48 VA |
| Holding | 5.11 VA |
| Construction | Marine-grade body, stainless steel actuator |
| Replaces | S20P, S20PSAK, M24E |
What it fits
It fits Weathermatic Nitro, 12000, and 21000 Silver Bullet series valves. If your valve leaks past a torn diaphragm instead of a bad coil, replace the diaphragm, not the solenoid.
- Cut power at the controller before you touch the wiring.
- Unthread the old solenoid by hand. No tools needed.
- Thread the S20PSA in until snug, then a quarter turn more.
- Splice the two leads to the field wires with waterproof connectors.
Specs & Details
| Product Name | Solenoid (S20PSA) |
| Manufacturer Part Number | S20PSA |
| Sku | TEL-581-1001 |
| UPC | 780534102141 |
