Toro 250-06-04

Hunter PGV100GS

Hunter PGV100G

Rain Bird B72421

Hunter PGV-101GS

Rain Bird B34183

Rain Bird B72311

Rain Bird B73000

Hunter HQ44LRC

Hunter PGV101G

Rain Bird B32953

Rain Bird B72110

Rain Bird B34383

Rain Bird B34213

Rain Bird B30410

Hunter ICV101G

Rain Bird B35213

Weathermatic MAX-DW-15

Weathermatic MAX-DW-10

Rain Bird B34583
Your controller sends 24V to a valve’s solenoid, which opens it to water that zone, then closes it when the station ends — one valve per zone. In-line solenoid valves do the automatic watering; anti-siphon valves add built-in backflow protection in the same body; and ball valves give you a reliable manual shut-off to isolate the system. Group the zone valves on a manifold inside a valve box for protected, serviceable access. Sizing the box? Read our How to Choose a Sprinkler Valve Box guide.
A controller energizes the valve’s 24V solenoid, which lifts the diaphragm and lets water through to that zone. When the station time ends, the solenoid de-energizes and the valve closes. One valve controls one zone.
Match the box to the number and size of valves it covers — a single valve fits a round box, while a manifold of two or more needs a rectangular jumbo box with room to service each solenoid. Our valve box guide walks the sizing.
Both are in-line solenoid valves. A globe valve has the inlet and outlet in a straight line; an angle valve turns the flow 90°, which saves a fitting at the base of a manifold or where the supply comes up from below.
An anti-siphon valve combines a zone valve with a built-in atmospheric vacuum breaker, so it both controls the zone and provides basic backflow protection. It must be installed at least 6 inches above the highest head and cannot be left under continuous pressure.
A ball valve opens and closes a quarter turn and seals reliably, which makes it the common modern choice for a mainline isolation point. Both isolate flow; ball valves are quicker to operate and less prone to seat wear.
