DIG SM50 Adjustable Micro Sprayer Kit

SM50

Write a Review Ask a question
In Stock
Rewards
Earn 35 points | Join or Sign In
Add product protection offered by
Quick Overview

DIG SM50 Adjustable Micro Sprayer Kit

Features

  • This comprehensive kit provides all the necessary components to easily install a system featuring eight adjustable micro sprayers, starting from an external garden hose faucet.

  • Enjoy the convenience of automation by utilizing one of DIG’s battery-operated or solar-powered controllers, ensuring efficient and hassle-free watering.

  • Experience expansion capabilities up to 1000 sq ft by incorporating additional 1/2″ drip tubing and micro sprayers, resulting in a remarkable total flow rate of up to 220 gallons per hour (GPH).

  • Each micro sprayer offers an adjustable flow rate, ranging from 0-26 GPH at 25 PSI, allowing precise control over water distribution.

  • Choose from three options of adjustable micro sprayers with 360°, 180°, and 90° patterns, providing flexibility to meet your specific watering needs.

  • This kit contains a total of 46 pieces, guaranteeing a complete installation package for your convenience.

  • Installation, expansion, and customization are made effortless due to the kit’s simplicity and user-friendly design.

  • Experience gentle watering with minimal water usage, reducing plant stress and minimizing water runoff compared to conventional sprinkler systems.

  • No need for glue or tools during installation, ensuring a hassle-free setup process.

  • Recommended spacing between micro sprayers is 8′ to 12′ apart, allowing for optimal water distribution.

  • Enjoy increased watering flexibility, adapting to the unique requirements of your garden or landscape.

  • The flexible poly tubing enables the irrigation system to smoothly curve along with the layout of your plants, providing enhanced versatility.

  • The micro sprayers feature an adjustable knob that regulates the flow, allowing for precise control over the wetting area’s diameter.

  • Enjoy flexibility in irrigation frequency, while simultaneously minimizing soil erosion and surface runoff.

  • Ideal for areas where low-flow overhead irrigation is preferred or in situations where drip emitters or conventional sprinkler systems are impractical.

Questions? Contact our support professionals:
Product Overview

What's in the Box...

  • 1 x 3/4" backflow preventer (part #D45)

  • 1 x 3/4" 25-PSI preset pressure regulator (part #D46)

  • 1 x 3/4" swivel adapter with screen (part #C34)

  • 1 x 50' roll of 1/2" drip tubing with .600" ID x .700" OD (part #B35)

  • 1 x 50' roll of 1/4" micro tubing with .170" ID x .250" OD (part #B38P)

  • 1 x 1/2" compression tee (part #c35)

  • 2 x 1/2" compression elbows (part #c36)

  • 1 x 1/2" compression coupling (part #c33)

  • 5 x 1/4" barbed connectors (part #H80)

  • 5 x 1/4" barbed tees (part #H82)

  • 2 x Adjustable micro sprayer assemblies with a 13" stake, poly riser and barb (part #308-1B) (180°, 0-26 GPH, up to a 10' radius)

  • 2 x Adjustable micro sprayer assemblies with a 13" stake, poly riser and barb (part #309-1B) (90°, 0-26 GPH, up to a 9' radius)

  • 1 x Adjustable micro sprayer assembly with a 13" stake, poly riser and barb (part #300-1B) (360°, 0-26 GPH, up to a 20' radius, full circle)

  • 3 x Adjustable micro sprayer on a 6" stake (part #410B) (360°, 0-20 GPH, up to a 10' diameter)

  • 5 x 1/2" holder stakes (part #R60)

  • 2 x Figure "8" hose ends (part #F68B)

  • 10 x Goof plugs (part #G79B)

  • 1 x Hole punch

  • 1 x Instruction manual

Specs & Details

Product Name SM50 Adjustable Micro Sprayer Kit
Manufacturer Part Number SM50
Sku DIG-SM50
